    Ppgi Sheet Door Frame Roll Forming Machine / Concrete Door Frame Making Machine

    Ask Lasest Price
    Model Number : door frame
    Certification : ce
    Payment Terms : T/T, L/C, Western Union
    Supply Ability : 20 sets per month
    Delivery Time : 30 days after received your payment
    • Product Details
    • Company Profile

    Ppgi Sheet Door Frame Roll Forming Machine / Concrete Door Frame Making Machine

    Door Frame Metal Roll Forming Machinery For Ppgi Sheet With Different Colors


    specification of metal roofing door frame roll forming machine

    No.Iron Door Frame Roll Forming Machine
    1Suitable materialcolor steel sheet, galvanized steel sheet, aluminium sheet
    2Material width1250mm or as your required
    3Material thickness0.3-0.8 or as your required
    4Working speed8-12m/min, can be 20m/min
    5Main motor power5.5kw with cycloidal with reducer
    6Hydraulic pump power4kw
    7Electrical control systemPLC control system with inverter
    8Shaft diameter70mm
    9Roller station16 rows, depend on your panel profile drawing
    10Rollerhigh grade 45# steel, hard chrome plating
    11Working time24 hours
    12workers1-2 only
    13Cutting head materialCr 12 mould steel with quenched treatment
    14Voltage380V 3Phase 50Hz or as your required
    15Weight4.5T
    16Dimension685mm*15mm*15mm


    FAQ about roll forming machine :
    Q:How is this machine's service life?A:In the normal maintenance,the service life at least 8 years.
    Q:How to maintenance?A:If using frequently,best coating lubricant on the chain and two ends of the shaft every month,replace the hydraulic oil every 1-2 years.
    Q:What can you do if the machine broken?A:Our machine's warranty period is 1 year,if the broken parts can't repair,we can free send the new parts replace the broken parts to you except the solenoid valve,the solenoid valve you must pay the express cost yourself.if after warranty period,we can through negotiationfor to solve the problems,and we supply the technical support for the whole life of the equipment.
    Q:Can you be responsible for transport?A:Yes,please tell me the destination port or address.we have rich experience in transport.
    Q:MissAlice,can you make the machine according to my design or proto type? A: Yes. We have an experienced team for working out the most suitable design and production plan for the machine that you are going to book with us.
    Q:How many workers operate this machine to manufacture?A:Only 1-2 worker.
    Q:Can you supply the raw materials?A:Yes,we can supply the galvanized steel coil,galvalume steel coil,color steel coil,and aluminum coil.
